Equipment and Services

From Louisiana to Job Sites Across the Globe—Manufacturing Solutions That Perform.

For decades, Frederick’s Manufacturing has been delivering precision-crafted products, custom fabrication, and dependable manufacturing services to industries across the USA and beyond. Backed by skilled people, proven expertise, and a commitment to quality, we provide solutions designed to meet your needs, keep projects moving, and perform in the toughest environments.

CNC Machines

Small CNC Machines

CNC Machine Types/Machine Swing and Travel

Our small CNC machines provide precise, repeatable machining for custom components, prototypes, and short-run production across a wide range of industrial applications.
By combining advanced CNC machining technology with skilled craftsmanship, Frederick’s Manufacturing delivers high-quality parts with exceptional accuracy, efficiency, and consistency.

HAAS VF-3YT/50	X = 40″ Y=26″ Z=25″, 4th Axis Chuck ID 3″
HASS VF-4	X = 50″ Y = 20″ Z = 25″, 4th Axis Chuck ID 2.5″
HAAS VF-5/50XT	X = 60″ Y=26″ Z=25″, 4th Axis Chuck ID 6″
HAAS VF-7/50	X = 84″ Y=30″ Z=30″, 4th Axis Chuck ID 7.5″
DOOSAN DMN-650	X = 50″ Y=28″ Z=24″, 4th Axis Chuck ID 8″ 120 degree 5th axis
MAZAK M5 80″	13 1/2″ Swing, 80″ Travel, 7 1/8″ Spindle Bore
MAZAK M5 80″	13 1/2″ Swing, 80″ Travel, 7 1/8″ Spindle Bore
MAZAK M5 80″	13 1/2″ Swing, 80″ Travel, 7 1/8″ Spindle Bore
MAZAK M5 80″	13 1/2″ Swing, 80″ Travel, 7 1/8″ Spindle Bore
MAZAK M5 120″	13 1/2″ Swing, 80″ Travel, 3 1/2″ Spindle Bore
MAZAK POWERMASTER CNC LATHE	22″ Swing, 120″ Travel, 10 1/4″ Spindle Bore
MAZAK QTN 3502KY – NEXUS II SERIES	26.77″ Max Swing X=8.875″ Travel Z=26″ Travel 4.4″ Spindle Bore 12″ Chuck
Doosan Puma 2600M	24.8″ Swing over the Carriage, 10.2″ X Axis, 32.67″ Z Axis On Center Live Milling
Doosan Puma 2600M	24.8″ Swing over the Carriage, 10.2″ X Axis, 32.67″ Z Axis On Center Live Milling
Doosan Puma 2100Y	Y Axis Lathe Max Work Length 29″ Max Turning Dia 18.9″ Chuck 10″ Main 6″ Sub X = 10.2″ y = 32.7″ z = 4″
Doosan Puma 2100Y	Y Axis Lathe Max Work Length 29″ Max Turning Dia 18.9″ Chuck 10″ Main 6″ Sub X = 10.2″ y = 32.7″ z = 4″
Doosan Puma 2600SY	Y Axis Lathe Max Work Length 29″ Max Turning Dia 18.9″ Chuck 10″ Main 6″ Sub X = 10.2″ y = 32.7″ z = 4″
Doosan Puma 2600SY	Y Axis Lathe Max Work Length 29″ Max Turning Dia 18.9″ Chuck 10″ Main 6″ Sub X = 10.2″ y = 32.7″ z = 4″
Doosan Puma 2600SY	Y Axis Lathe Max Work Length 29″ Max Turning Dia 18.9″ Chuck 10″ Main 6″ Sub X = 10.2″ y = 32.7″ z = 4″
DOOSAN PUMA 300LM TURNING CENTER	17.7″ Swing over the Carriage, 9.8″ X Axis 26.8″ Z Axis On Center Live Milling
DOOSAN PUMA 400LMC TURNING CENTER	23.2″ Swing over the Carriage, 14.3″ X Axis 84.8″ Z Axis On Center Live Milling

Large Sub Sea CNC Machines

DOOSAN PUMA VTS 1620M Vertical Turning Center	78.7” Max Turning Dia. 63” 4 Jaw Manual Chuck 63” Max Turning Height 22,000lb Load Capacity 2 Simultaneously Controllable Axes, 14.3″ X Axis 84.8″ Z Axis, On Center Live Milling
DOOSAN PUMA VTS 1620M Vertical Turning Center	78.7” Max Turning Dia. 63” 4 Jaw Manual Chuck 63” Max Turning Height 22,000lb Load Capacity 2 Simultaneously Controllable Axes, 14.3″ X Axis 84.8″ Z Axis, On Center Live Milling
DEAWOO DB130C HORIZONTAL BROING MILL	x = 118.1” y = 78.7” z= 63” 360 Degree Rotation, “A” Axis 360 Degree Rotation W/24 ½” OD, Four Chuck Jaw, 33,000lbs Capacity Table, 71” X 63”
DEAWOO DB130C HORIZONTAL BROING MILL	x = 118.1” y = 78.7” z= 63” 360 Degree Rotation, “A” Axis 360 Degree Rotation W/24 ½” OD, Four Chuck Jaw, 33,000lbs Capacity Table, 71” X 63”
DEAWOO DB130C HORIZONTAL BROING MILL	x = 118.1” y = 78.7” z= 63” 360 Degree Rotation, “A” Axis 360 Degree Rotation W/24 ½” OD, Four Chuck Jaw, 33,000lbs Capacity Table, 71” X 63”
MORI SEIKI LL8 TURNING CENTER	52” Swing, 100” Travel, 29.5” Over the Carriage, 68” Between the Chucks, Spindle Bore
DOOSAN PUMA 700LM TURNING CENTER	35.4” Swing, 7.5” Thru Bore, 126” Max Turning Length, w? Live Tooling
DOOSAN PUMA 800LM TURNING CENTER	42” Swing, 10.5” Thru Bore, 60” Between Centers,, W/ Live Tooling

Waterjet Cutting Machine

FLOW JET MACH 500 3060 XD WATERJET	24ft by 10ft table with 5 axis

Water Cutting

Water Cutting Division

The Flow Mach 500 3060 XD Single Zone Waterjet delivers precise, high-quality cutting for a wide range of materials, including steel, stainless steel, aluminum, and specialty alloys, without introducing heat-affected zones.

Using advanced waterjet cutting technology, Frederick’s Manufacturing provides accurate fabrication solutions for complex components, custom metal parts, and demanding industrial applications requiring exceptional precision and efficiency.

Capabilities:

Work Envelope is 10′ wide by 24’ long,
Fully Programmable, Servo-driven Z Axis, 50hp 6500 Bar 95,000psi, automatic taper compensation for tight tolerances, 3D 5Axis Capability
Waterjet Shop will cut 24 hrs, 7 days a week.
We will cut plate for other companies as we can fit in jobs.

Subsea

Subsea Division

In the Fabrication department we can fabricate just about anything that will fit through a 15ft wide by 40ft high door. We can drive an 18 wheeler in one end of the shop and out the other. We are equipped with two 15 ton overhead cranes, and have a 15 ton cherry picker.

Some examples are:

Mud Mats & Assemblies
Pipe Clamps
Tanks
Baskets

Aluminum & Stainless Fabrication Division

We fabricate Stainless Steel and Aluminum parts for the Oil & Gas Industry in a very clean environment.

Some examples are:

Skids
Tanks
Frames
Tool Boxes

Job Shop

Job Shop Division, where we have both CNC and Manual Lathe and Milling capabilities for the one only or multiple manufacturing and repair work. We are equipped with 3 over head cranes, one in the saw shop (2 ton) and one in the new job shop (5 ton) for larger oilfield components. All machines are equipped with jib cranes to handle all medium sized parts. Some examples are:

Packer Parts
Down Hole Tools
Crossover Subs
Hydraulic Cylinders
Shafts
Turning and Threading Pipe

Our skilled team is at the heart of everything we do. Through ongoing training, advanced manufacturing capabilities, and a strong commitment to Health, Safety, and Quality, we deliver products and services that meet the highest standards.

Welding Machines

Welding

CNC Machine Types/Machine Swing and Travel

Our CNC machining capabilities include a wide range of machine types, swing capacities, and travel dimensions, allowing us to efficiently manufacture components of varying sizes and complexities.
With advanced CNC equipment and flexible machining capacity, Frederick’s Manufacturing delivers precision-engineered parts for industrial, energy, and manufacturing applications across North America.

MILLER DIALARC 250-AC/DC
MILLER DIMENSION 452 PWR SOURCE
MILLER 22A 24V WIRE FEED
HYPERTHERM POWERMAX 800
MILLER DIMENSION 452 PWR SOURCE
MILLER 60 SERIES 24V WIRE FEED
MILLER CP-200 POWER SOURCE
MILLER S-22A 24V WIRE FEED
MILLER 22A 24V WIRE FEED
MILLER DIMENSION 452 PWR SOURCE
MILLER 22A 24V WIRE FEED
LINCOLN DC-1000 PWR SOURCE
LINCOLN DC-NA-3N AUTO WIRE FEED
A&N POSITIONER VP100 11K CAPACITY
MILLER DIMENSION 452 PWR SOURCE
MILLER 22A 24V WIRE FEED
MILLER BOBCAT 225
A&N POSITIONER PT100 220 LB CAP.
A&N POSITIONER PT100 220 LB CAP.
MILLER DELTAWELD 452 PWR SOURCE
MILLER S-22A 24V WIRE FEED
MILLER DIMENSION 452 PWR SOURCE
MILLER 22A 24V WIRE FEED
LINCOLN AC-1200 POWER SOURCE
LINCOLN AC-NA-4 AUTO WIRE FEED
LINCOLN DC-1000 PWR SOURCE
LINCOLN DC NA3N AUTO WIRE FEED
LINCOLN AC 1200 POWER SOURCE
LINCOLN AC NA-4 WIRE FEED
MILLER DIMENSION 452 PWR SOURCE

MILLER 22A 24V WIRE FEED
A&N MCB 3×2.5 MANIPULATOR
A&N POSITIONER VP100 11K CAPACITY
C&B HERRICK 6×6 MANIPULATOR
MILLER CP302 POWER SOURCE
MILLER HF-2510-1 TIG WIRE FEED
HENKEL ROUND ROD OVEN
HENKEL ROUND ROD OVEN
HENKLE PORTABLE ROD OVEN
HENKLE PORTABLE ROD OVEN
X-9 CUSTOM MADE 5000# PRESS
DELTA SHOPMASTER BELT SANDER
DELTA 6″ BENCH GRINDER
LINCOLN AC 600 POWER SOURCE
LINCOLN AC NA-4 WIRE FEED
Hypertherm Powermax 65
Hypertherm Powermax 85
Millermatic 252
Millermatic 252
Miller Alumapower 350MPa
Liller Alumafeed Wire Feeder
Miller Alumapower 350MPa
Liller Alumafeed Wire Feeder
Syncrowave 250DX- Tig Runner with Torch
Syncrowave 250DX- Tig Runner with Torch
Millermatic 252
Millermatic 252
Millermatic 252

Our Four Divisions:

Job Shop Sub Sea Machining – Fabrication Wireline Water Jet Cutting

Privacy Policy| Do Not Share My Information| Conditions of Use| Notice and Take Down Policy| Website Accessibility Policy

Manual Machines

Manual

Manual Machine Types/Machine Swing and Travel

Lagun Manual Mills deliver precision machining capabilities for custom metal fabrication, prototyping, and production applications, helping Frederick’s Manufacturing maintain the highest standards of quality and accuracy.
With versatile manual milling equipment and experienced machinists, we provide reliable machining services for complex components across the oil & gas, industrial, and manufacturing sectors.

LAGUN MANUAL MILL X-36, Y-15, Z-16	X = 36″ Y = 15″ Z = 16″ 4th Axis Chuck ID 2.5′ and 3.5″
17″ KINGSTON ENGINE LATHE	10 5/8″ Swing 31 1/2″ Travel 2.30″ Spindle Bore
17″ CLAUSING ENGINE LATHE	10 1/2″ Swing 80″ Travel 3 1/16″ Spindle Bore
21″ MAZAK ENGINE LATHE	10 1/8″ Swing 80″ Travel 3 1/8″ Spindle Bore
24″ MAZAK ENGINE LATHE	14 1/2″ Swing 80″ Travel 4 1/8″ Spindle Bore
24″ MAZAK ENGINE LATHE	14 1/2″ Swing 160″ Travel 4 1/8″ Spindle Bore
24″ MAZAK ENGINE LATHE	14 1/2″ Swing 160″ Travel 4 1/8″ Spindle Bore
24″ MAZAK ENGINE LATHE	14 1/2″ Swing 120″ Travel 4 1/8″ Spindle Bore
24″ MAZAK ENGINE LATHE	14 1/2″ Swing 80″ Travel 4 1/8″ Spindle Bore
30″ MAZAK ENGINE LATHE	21″ Swing 80″ Travel 4 1/8″ Spindle Bore
KARAKI 12″ HOLOW SPINDLE	22″ Swing 120″ Travel 12″ Spindle Bore
WARNER SWASEY 3A TURRET LATHE	24 1/2″ Swing 43″ Travel 6 1/4″ Spindle Bore
WHACHEON HL-460	18″ Swing 40″ Travel 2 3/64″ Spindle Bore
WHACHEON HL-460	18″ Swing 40″ Travel 2 3/64″ Spindle Bore

Additional Equipment

All Additional Equipment to Expand Capabilities

Our stress relief oven services help reduce residual stresses in welded and machined components, improving dimensional stability, durability, and long-term performance.
By combining controlled heat treatment processes with experienced quality oversight, Frederick’s Manufacturing delivers reliable stress relieving solutions for critical industrial, energy, and heavy equipment applications.

STRESS RELIEF OVEN	10’ X 10’ X 6’ High 1200º Max Heat Cal Quarterly Surveyed Annually
PHOSPHATE TANK	2’ X 2’ X 10’ Size Tank
BANDSAW, PORTABLE JET	2” Max Cut
BANDSAW, HEM AUTOMATIC	12” Max Cut
BANDSAW, MARVEL	19” Max Cut
BANDSAW, MARVEL	24” Max Cut
SUNNEN HONE	From 1-7/8” ID to 24” ID, Max Length 18’

Frederick's Manufacturing LLC Certificates

Certificate of Authority to Use the Official API Monogram
ISO 9001-2015
Certificate of Registration: API Spec Q1, 9^th Edition

Industries we serve

We provide manufacturing capabilities across multiple industries following a world class quality system which complies with all applicable industry standards.

Oil & Gas
Marine & Offshore
Industrial
Solar/Renewable Energy
Petrochemical
Agriculture
Construction & Infastructure
Tenchless /HDD

Sales & support

We are dedicated to excellence and committed to customer satisfaction. Contact us for all sales, support and general queries.
